If you want to produce t-shirt bag or vest bag, need a support equipment Hydraulic Punching Machine. (please check detail information of this machine in” Machine Associated Equipment)
It is used for producing vest bags and flat-opening bags with printing.
USE
It is used for producing vest bags and flat-opening bags with printing. The main motor adopts frequency conversion motor to save more electricity and regulate speed more freely. The color code tracker with good performance makes the sealing and cutting length more accurately and the error smaller .it adopts advanced computer to adjust length more freely and accurately.
| Model | 600 | 700 | 800 | 1000 | 1200 |
| Max.Width of bag-making(mm) | 600 | 700 | 800 | 980 | 1150 |
| Max.Length of bag-making(mm) | 1000 | 1000 | 1000 | 1200 | 2000 |
| Speed of bag-making(pc/min) | 30-130 | 30-130 | 30-130 | 30-120 | 30-100 |
| Power of motor(kw) | 1 | 1.1 | 1.5 | 2.2 | 3 |
| Weight(kg) | 700 | 750 | 800 | 900 | 1000 |
| External dimension(LXWXH)mm | 2900X1300X1500 | 2900X1400X1600 | 2900X1500X1600 | 3200X1800X1700 | 3400X1900X1800 |
If you want to produce t-shirt bag or vest bag, need a support equipment Hydraulic Punching Machine. (please check detail information of this machine in” Machine Associated Equipment)
