The machine is used for making plastic film packing bags with the material of polyethylene film, compound pearl cotton for hardware, electric products and small electric appliances.
Use:
The machine is used for making plastic film packing bags with the material of polyethylene film, compound pearl cotton for hardware, electric products and small electric appliances.
The Function and Characteristic:
1. The microcomputer control and step motor are adopted for the whole machine to draw
Materials (servo motor control system for option).
2. Computer fixing length, accurate and stable.
3. Automatic counter, count alarm and setting to stop machine.
4. It can finish the processing from materials to bag one time, featuring in reducing site coverage, processing and labor cost.
Main Technical Variables:
| Model | KDB-600 | KDB-800 | KDB-1000 | KDB-1200 |
| Product length | 80-600 MM | 80-800 MM | 90-900 MM | 300-1100 MM |
| Product width | 80-999 MM | 80-999 MM | 80-999 MM | 80-999 MM |
| Machine speed(pc/min) | 30-150 MM | 30-150 MM | 30-150 MM | 30-150 MM |
| Total power | 3.5 KW | 4 KW | 5.5 KW | 7.5 KW |
| Weight | 900 KG | 1000KG | 1100KG | 1200KG |
| Dimension | 4800*1800*1450MM | 5000*2000*1500MM | 5500*2500*1700MM | 5500*3000*1700MM |
