This machine set is used for blowing Low-density polyethylene(LDPE)and high-density polyethyene(HDPE)plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the food industry, gamenet industry and textile industry, etc.
Use
This machine set is used for blowing Low-density polyethylene(LDPE)and high-density polyethyene(HDPE)plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the food industry, gamenet industry and textile industry, etc.
Main Technical Variabless
| Model | SJ-55FM-600 | SJ-60FM-700 | SJ-65FM-800 |
| Screw Diameter | 55mm | 60mm | 65mm |
| Screw Ratio | 1:28 | 1:28 | 1:28 |
| Screw Speed | 10-110r/min | 10-110r/min | 10-110r/min |
| Max.Output | 45kg/h | 65kg/h | 85kg/h |
| Max.Folding Width of Film | 500mm×2 | 600mm×2 | 700mm×2 |
| Single-sided Thickness of Film | 0.006-0.10mm | 0.006-0.10mm | 0.006-0.10mm |
| Power of Main Motor | 15Kw | 18.5Kw | 22Kw |
| Total Power | 26Kw | 30Kw | 40Kw |
| Weight of Machine | 3000kg | 3800kg | 4500kg |
| Overall Dimensions | 4800×2200×3800 | 5000×2400×4000 | 5200×2600×4200 |
